D Horizontal Multistage Centrifugal Pump

This series of horizontal multistage pumps use national energy-saving hydraulic model, developed and updated constantly by our factory, with the advantage of high efficiency, wide range of performance, safety and smooth operation, low noise, easy installation and maintenance, long life, and its technology level is in the domestic leading position, product performance is reliable.
Availability:
Quantity:

This series of horizontal multistage pumps use national energy-saving hydraulic model, developed and updated constantly by our factory, with the advantage of high efficiency, wide range of performance, safety and smooth operation, low noise, easy installation and maintenance, long life, and its technology level is in the domestic leading position, product performance is reliable.



1) Type D pump is used in mine and urban project for delivering clear water without solid particles or other liquids which are physically or chemically similar to clear water. The temperature of liquids are not be over 80 °C.



2) Type MD pump is used to deliver nertral water with solid particles below 1.5% (viscosity less than 0.5mm) and other sewage. It is suitable for using in steel factory and mine etc. The temperature of liquids can not exceed 80°C.



3) Type DF pump is used for delivering corrosive liquids without solid particles, the temperature of liquids is -20 °C ~105 °C.



4) Type DY pump is used for delivering oil and pertroleum products without solid particles and viscosity below 120 centistokes, the temperature of liquids is -20 °C ~150 °C. The inlet pressure of all above pumps is less than 0.6Mpa.

1. This series pump is a horizontal, single suction, multi stage centrifugal pump section, the suction is in horizontal direction, and outlet is vertical upward. Water suction, middle, discharge section, bearing housing and pump body are bolted into one strain, and select stages according to the pump head.
2. Rotor includes shaft, impeller, shaft sleeve, balance disk, and other parts. Axis parts are connected through the flat keys and the shaft nuts. The rotor is supported by the rotor bearings or sliding bearings in both ends, the bearing does not bear axial force, axial force is balanced by the balance disc. Bearings lubricated with grease, sliding bearings lubricated with light oil, and oil ring lubrication, and cooled by circulating water.
3. Shaft seal in the form of two kinds, mechanical seals and packing seal. When use packing seal, the packing ring should be placed at the right location, the tightness of packing must be appropriate to the liquid oozing drop by drop. Various sealing elements is in a sealed chamber, the chamber must be filled with some water, as water seal, water cooled or water lubrication. At the seal there is replacable sleeve, to protect the shaft.
4. From the motor direction, the pump is clockwise rotation.
Part Name D MD DY DF
Suction casing HT250 ZGCr17Mo2-CuR HT250/ZG230-450 Cast steel or Cast stainless steel
Stage casing HT250 ZGCr17Mo2-CuR HT250/ZG230-450 Cast steel or cast stainless steel
Discharge casing HT250 ZGCr17Mo2-CuR HT250/ZG230-450 Cast steel or cast stainless steel
Impeller HT250 KmTBCr15Mo3 HT250/ZG230-450 Cast steel or cast stainless steel
Diffuser HT250 KmTBCr15Mo3 HT250/ZG230-450 Cast steel or cast stainless steel
Shaft 45# 45# 45# stainless steel
Balance disc ZQA19-4 ZGCr17Mo2-CuR ZQA19-4 Cast steel or cast stainless steel
