Diaphragm pump application advantages

Views: 0     Author: Site Editor     Publish Time: 2020-07-10      Origin: Site

Diaphragm pump application advantages

Diaphragm pump is a new type of conveying machinery that can convey various corrosive liquids, liquids with particles, high viscosity, volatile, flammable, and highly toxic liquids. Diaphragm pump has four materials: plastic, aluminum alloy, cast iron, stainless steel.


This article contains the following:

  • Air powered

  • Reliable and low-cost diaphragm pumps in flammable and explosive environments

  • Diaphragm pump is not easy to block

  • Can transport unstable fluids

  • Diaphragm pump can separate materials

  • Diaphragm pump is simple and economical


Diaphragm pump application advantages

Diaphragm pumps are made of nitrile rubber, neoprene rubber, fluororubber, polytetrafluoroethylene, polytetrafluoroethylene according to different liquid media. To meet the needs of different users. It has been installed on various special occasions and used to pump media that cannot be pumped by conventional pumps, and has achieved satisfactory results.

Diaphragm pumps have an absolute dominant position in the paint and ceramics industry. The advantages of pneumatic diaphragm pumps are:


Air powered

Because air is used as the power, the flow rate is automatically adjusted with the change of back pressure (outlet resistance), suitable for medium to high viscosity fluids. The working point of the centrifugal pump is set based on water. If it is used for a fluid with a slightly higher viscosity, a speed reducer or frequency converter is required, and the cost is greatly increased. The same is true for the gear pump.


Reliable and low-cost diaphragm pumps in flammable and explosive environments

The use of pneumatic pumps in a flammable and explosive environment is reliable and low cost, such as the transportation of fuel, gunpowder, and explosives, because: first, it is impossible to generate sparks after grounding; second, no heat is generated during work, the machine It will overheat; third, the fluid will not overheat because the diaphragm pump has minimal agitation of the fluid.


Diaphragm pump is not easy to block

In harsh places, such as construction site, industrial and mining wastewater discharge, due to the large amount of impurities in the sewage and the complex composition, the pipeline is easily blocked, so that the electric pump is overloaded and the motor is vulnerable to heat. The pneumatic diaphragm pump can pass particles and the flow rate is adjustable. When the pipeline is blocked, it will automatically stop until it is smooth.


Can transport unstable fluids

It can be used to transport fluids with relatively unstable chemical properties, such as photosensitive materials and flocculants. This is because the shear force of the diaphragm pump is low and the physical impact on the material is small.


Diaphragm pump can separate materials

In the treatment of hazardous and corrosive materials, the diaphragm pump can completely separate the materials from the outside world.


Diaphragm pump is simple and economical

In some tests, it is ensured that no impurities contaminate the raw materials.

In addition, the diaphragm pump is small and easy to move, does not require a foundation, takes up very little ground, and is simple and economical to install. Can be used as a mobile material delivery pump.
