TSWA type pump is multistage sectional centrifugal pump.Its inlet is placed horizontally at the inlet section,and its outlet is placed vertically upwards at the outlet section.The customer can select different types of pump in accordance with the different requirement on head.The pump stator is mainly made up of inlet,middle,outlet section,tail cover and bearing body,etc.The pump rotor is made up of pump,impeller,shaft sleeve and balance plate,etc.The joint face of inlet,middle,and outlet section is sealed with paper pad.The asbestos is used to seal between shaft sleeves so as not to let water enter the bearing along the shaft.The stuffing seal is used in the shaft seal of two ends of the pump.Through the adjustment on tightening bolt,the liquid then can leak out drop by drop.The bearing adopts rolling bearing,and calcium solid lubricant is applied inside the bearing.The pump rotates clockwise from the direction of drive end.
Applications
1. Mainly used in high buildings life water supply, fire fighting system, automatic spraying water under the water curtain, long distance water transportation, water circulation in production process, supporting the use of all kinds of equipment and various production process water, etc
2. It is used in city construction, factories, mines, the water is especially suitable for hotels, restaurants, entertainment refrigeration and air conditioning supply water.
TSWA type pump is multistage sectional centrifugal pump.Its inlet is placed horizontally at the inlet section,and its outlet is placed vertically upwards at the outlet section.The customer can select different types of pump in accordance with the different requirement on head.The pump stator is mainly made up of inlet,middle,outlet section,tail cover and bearing body,etc.The pump rotor is made up of pump,impeller,shaft sleeve and balance plate,etc.The joint face of inlet,middle,and outlet section is sealed with paper pad.The asbestos is used to seal between shaft sleeves so as not to let water enter the bearing along the shaft.The stuffing seal is used in the shaft seal of two ends of the pump.Through the adjustment on tightening bolt,the liquid then can leak out drop by drop.The bearing adopts rolling bearing,and calcium solid lubricant is applied inside the bearing.The pump rotates clockwise from the direction of drive end.
Applications
1. Mainly used in high buildings life water supply, fire fighting system, automatic spraying water under the water curtain, long distance water transportation, water circulation in production process, supporting the use of all kinds of equipment and various production process water, etc
2. It is used in city construction, factories, mines, the water is especially suitable for hotels, restaurants, entertainment refrigeration and air conditioning supply water.
During the daily use of the self-priming pump, there will be some more common problems. For example, the self-priming pump's non-pumping problem will be caused by many different reasons, so how do we deal with these problems is the key. The reasons why the self-priming pump does not pump water include the following aspects.
The hot water submersible pump is used for hot spring bathing, and can also be used for extracting groundwater from deep wells, and can also be used for water lifting projects such as rivers, reservoirs, and canals. It is mainly used for farmland irrigation and human and animal water in high mountain areas. It can also be used for central air conditioning cooling, heat pump units, cold pump units, cities, factories, railways, mines, and construction site drainage. The general flow rate can reach 5~650m³/h, and the head can reach 10-550 meters.
Diaphragm pump is a new type of conveying machinery that can convey various corrosive liquids, liquids with particles, high viscosity, volatile, flammable, and highly toxic liquids. Diaphragm pump has four materials: plastic, aluminum alloy, cast iron, stainless steel.
